Heater voltageb

Operating (<15s response)

4.2VDC±0.1VDC (~1.7A)

Standby

2VDC (~0.85A)

Operating (<4s response)

4.55VDC±0.1VDC (~1.85A)

Standby

2VDC (~0.85A)

Pump impedance at 700°C

< 6kΩ

Permissible gas temperature

-100°C to +400°C

Gas flow rate

0 - 10 m/s

Repetitive permissible acceleration

5g

Incidental permissible acceleration

30g

OUTPUT VALUES

Oxygen pressure range

2mbar—3bar max

Accuracy

5mbar max

Internal operational temperature

700°C

Response time (10—90% step)

Standard response sensor

< 15s

Fast response sensor

< 4s

Warm up time (prior to sensor operation)

60s

Warm up time (from standby)

20s

Output stabilisation time

~ 180s
