Solar Radiation Sensor - Quantum PAR - SOL-PAR

? Range?: Wavelengths of from 400-700 nm?
? Accuracy?: Maximum ± 5%?
? Stability?: <±2% change over a 1 year period?
? Response Time?: 10 μs?
? Temperature Dependence?: 0.15% per °C maximum?
? Operating Temperature?: -40°C to +65°C
? Operating Humidity?: 0 to 100%?

Model Number: SOL-PAR
Data Sheet:

Quantity:: - +

Inquire Now Add to cart

Mouse over image to zoom

Product Specification

SOL-PAR Quantum Solar Sensor Description
The Quantum Solar Sensor is designed for measurements in solar, agricultural, meteorological, ecological and other environmental fields. It measures photosynthetically active radiation (PAR). Accurate measurements in the range of 400 to 700 nm are obtained under natural and artificial light conditions.

The sensor features a silicon photovoltaic detector mounted in a fully cosine-corrected miniature head. Colored glass filters are used to tailor the silicon photodiode response to the desired quantum response and an interference filter is used to provide a sharp cutoff at 700 nm.

The Quantum Solar Sensor is mounted on a leveling base and is available with either a flat base or plug-in mount to fit the RainWise Quadpod or Monopod mounting systems. It is manufactured of high stability silicon (detector), aluminum, stainless steel and PVC (base for RainWise Mount).

SOL-PAR Quantum Solar Sensor Specifications

Range	Wavelengths of from 400-700 nm
Accuracy	Maximum ± 5%
Sensitivity	Typical 5μA per 1000μmol s^-1m^-2
Linearity	Maximum deviation of 1% up to 10,000μmol s^-1m^-2
Stability	<±2% change over a 1 year period
Response Time	10 μs
Temperature Dependence	0.15% per °C maximum
Cosine Correction	Cosine corrected up to 80° angle of incidence
Azimuth	<±1% error over 360° at 45° elevation
Operating Temperature	-40°C to +65°C
Operating Humidity	0 to 100%
